Quikr Adapter Type 2 to GB/T DC 400A, chinese standard (2-Years Warranty)
48,599
💳 Installments starting from 8100 EGP/mo
×
Easy Pay
Select your preferred plan
BNPL
Banks
Description
QUIKR Type 2 to GB/T DC Fast Charging Adapter
The QUIKR Type 2 to GB/T DC Fast Charging Adapter is designed for high-power EV charging, supporting up to 400A continuous current and 1000V DC maximum voltage. It features silver-plated copper alloy connectors for low contact impedance and reduced heat generation, along with a UL94V-0 flame-retardant rubber shell and durable thermoplastic casing. With an IP54 rating when mated and an operating temperature range of -30°C to +50°C, the adapter is designed for reliable use in different weather conditions.
Specifications
| Specification | Details |
|---|---|
| Product Model | QUIKR Type 2-GB/T V2 400A |
| Rated Current | 400A Max |
| Rated Voltage | 1000V DC Max |
| Contact Impedance | ≤ 0.5 mΩ Max |
| Waterproof Grade | IP54 (Mating) |
| Fireproof Grade | UL94V-0 (Rubber Shell) |
| Plastic Shell Material | Thermoplastic Plastic |
| Conductor Material | Copper Alloy, Silver-Plated Surface |
| Working Temperature | -30°C to +50°C |
| Terminal Temperature Rise | < 50K |
| Insertion & Extraction Force | < 100N |
| Dimensions (L × W × H) | 287.05 × 93.8 × 171.45 mm |
| Certifications | CE Certified |
| Warranty | 2-years |
Key Features
- 400A Max Current: Supports up to 400A continuous current for high-power DC fast charging.
- 1000V DC Max: Designed to support charging systems with up to 1000V DC.
- Low Contact Impedance: ≤ 0.5 mΩ Max for efficient power transfer and reduced heat generation.
- Flame-Retardant Construction: Features a UL94V-0-rated rubber shell and thermoplastic plastic casing.
- IP54 Protection: Provides waterproof protection when the adapter is mated.
- Wide Operating Temperature: Suitable for operation from -30°C to +50°C.
- CE Certified: Certified for applicable safety and performance requirements.
