ETEC EV Charger Cable type 2 to type 2 (5-meter Cable 32A 22kW, EV European standard Plug), (2-Years Warranty by XPRS)
11,629
💳 Installments starting from 1938 EGP/mo
×
Easy Pay
Select your preferred plan
BNPL
Banks
Description
The ETEC EKEP3-T2-D-32 is a three-phase Type 2 to Type 2 EV charging cable designed to connect an electric vehicle to a compatible charging station. Rated at 32A and 400V, it supports up to 22kW charging and comes with a 5-meter black straight cable. The cable uses a flame-retardant thermoplastic housing and silver-plated copper-alloy pins, with insulation, mechanical, and environmental protection features designed for EV charging applications. It complies with the IEC 62196-2 charging connector standard.
Specifications
| Specification | Details |
|---|---|
| Product Model | EKEP3-T2-D-32 |
| Cable Type | Type 2 to Type 2 |
| Phase | Three Phase |
| Rated Current | 32A |
| Operation Voltage | 400V ±10% |
| Maximum Charging Power | 22kW |
| Cable Length | 5 Meters |
| Cable Type | Black Straight Cable |
| Case Material | Thermoplastic, Flame Retardant Grade UL94 V-0 |
| Pin Material | Copper Alloy, Silver + Thermoplastic on the Top |
| Insulation Resistance | >500MΩ (DC500V) |
| Conductive Terminal Temperature Rise | ≤50K |
| Withstand Voltage | 2500V/min |
| Contact Resistance | ≤0.3Ω |
| Mechanical Life | No-load Plug in / Pull Out >50,000 Times |
| Coupled Insertion Force | 45N–80N |
| Impact Resistance | Tolerable to 2-ton car rolling or 1m height drop without damage |
| Temperature Range | -40°C to +50°C |
| Protection Degree | IP55 |
| Humidity | <85% |
| Charging Standard | IEC 62196-2 |
Features
- 22kW Three-Phase Charging: 32A rated current and 400V ±10% operating voltage.
- Type 2 to Type 2 Connection: Designed for connection between the charging station and electric vehicle.
- 5-Meter Cable: Supplied with a standard 5-meter black straight cable.
- Flame-Retardant Housing: Thermoplastic case with UL94 V-0 flame-retardant grade.
- Durable Conductors: Copper-alloy pins with a silver-plated surface.
- IP55 Protection: Provides protection suitable for the specified environmental conditions.
- High Mechanical Durability: Rated for more than 50,000 no-load plug-in/pull-out cycles.
- Impact Resistance: Designed to tolerate a 2-ton car rolling over the cable or a 1-meter drop without damage.
- Wide Temperature Range: Suitable for use from -40°C to +50°C.
Application
The cable is intended for use with EV charging stations in locations such as professional charging stations, parking lots, parking spaces, and residential parking lots.
